Renesas H8S/2111B User Manual
Page 39
Rev. 1.00, 05/04, page 5 of 544
Pin
Name
Pin No.
Single-Chip Modes
Flash Memory
TFP-144
Mode 2, Mode 3 (EXPE = 0)
Programmer Mode
31
PE1
NC
32
PE0
NC
33 (B)
PA7/
KIN15/PS2CD
NC
34 (B)
PA6/
KIN14/PS2CC
NC
35 (B)
PA5/
KIN13/PS2BD
NC
36
VCCB
VCC
37 (B)
PA4/
KIN12/PS2BC
NC
38 (B)
PA3/
KIN11/PS2AD
NC
39 (B)
PA2/
KIN10/PS2AC
NC
40 (B)
PA1/
KIN9
NC
41 (B)
PA0/
KIN8
NC
42
VSS
VSS
43
PF7/TMOY*
NC
44
PF6/ExTMOX*
NC
45
PF5/ExTMIY*
NC
46
PF4/ExTMIX*
NC
47
PF3/TMOB
NC
48
PF2/TMOA
NC
49
PF1/TMIB
NC
50
PF0/TMIA
NC
51 (N)
PG7/ExSCLB*
NC
52 (N)
PG6/ExSDAB*
NC
53 (N)
PG5/ExSCLA*
NC
54 (N)
PG4/ExSDAA*
NC
55
(N)
PG3
NC
56
(N)
PG2
NC
57
(N)
PG1
NC
58
(N)
PG0
NC
59
PD7
NC
60
PD6
NC
