Table 10.4 Registers Accessible by TMR_X/TMR_Y
TMRX/Y H'FFF0 H'FFF1 H'FFF2 H'FFF3 H'FFF4 H'FFF5 H'FFF6 H'FFF7
0 TMR_X
TCR_X
TMR_X
TCSR_X
TMR_X
TICRR
TMR_X
TICRF
TMR_X
TCNT
TMR_X
TCORC
TMR_X
TCORA_X
TMR_X
TCORB_X
1 TMR_Y
TCR_Y
TMR_Y
TCSR_Y
TMR_Y
TCORA_Y
TMR_Y
TCORB_Y
TMR_Y
TCNT_Y
TMR_Y
TISR
10.3.11 Timer XY Control Register (TCRXY)
TCRXY selects the TMR_X and TMR_Y output pins and internal clock.
Bit Bit
Name
Initial
Value
R/W Description
7
IOSX
0
R/W
TMR_X I/O Select
0: Output to P67/TMOX and input from P60/TMIX
1: Output to PF6/ExTMOX and input from PF4/ExTMIX
6
IOSY
0
R/W
TMR_Y Output Enable
0: Output to PF7/TMOY is prohibited and input from
P62/TMIY
1: Output to PF7/TMOY is permitted and input from
PF5/ExTMIY
5 CKSX
0 R/W
TMR_X
Clock
Select
For details about selection, see the clock conditions in
table 10.3.
4 CKSY
0 R/W
TMR_Y
Clock
Select
For details about selection, see the clock conditions in
table 10.3.
3 to 0
—
All 0
R/W
Reserved
The initial value should not be changed.
Note: * The program development tool (emulator) does not support TCRXY.
