Rev. 1.00, 05/04, page 195 of 544

Table 10.3 Clock Input to TCNT and Count Condition (3)

TCR

TCRAB

Channel

CKS2 CKS1 CKS0 CKSA CKSB Description

TMR_B

0 0 0 — 0 Disables

clock

input

0 0 1 — 0 Increments

at

φ/4

0 1 0 — 0 Increments

at

φ/256

0 1 1 — 0 Increments

at

φ/2048

1 0 0 — 0 Disables

clock

input

0 0 0 — 1 Disables

clock

input

0 0 1 — 1 Increments

at

φ/4096

0 1 0 — 1 Increments

at

φ/8192

0 1 1 — 1 Increments

at

φ/16384

1

0

0

1

Increments at overflow signal from
TCNT_A*

1

0

1

Increments at rising edge of external
clock

1

1

0

Increments at falling edge of external
clock

1

1

1

Increments at both rising and falling
edges of external clock

TMR_A

0 0 0 0 — Disables

clock

input

0 0 1 0 — Increments

at

φ

0 1 0 0 — Increments

at

φ/2

0 1 1 0 — Increments

at

φ/4

1 0 0 0 — Disables

clock

input

0 0 0 1 — Disables

clock

input

0 0 1 1 — Increments

at

φ/2048

0 1 0 1 — Increments

at

φ/4096

0 1 1 1 — Increments

at

φ/8192

1

0

0

1

Increments at compare-match A from
TCNT_B*

1

0

1

Increments at rising edge of external
clock

1

1

0

Increments at falling edge of external
clock

1

1

1

Increments at both rising and falling
edges of external clock

Notes: * If the TMR_B clock input is set as the TCNT_A overflow signal and the TMR_A clock

input is set as the TCNT_B compare-match signal simultaneously, a count-up clock
cannot be generated. These settings should not be made.
