Renesas H8S/2111B - Manual (Page 41)

Rev. 1.00, 05/04, page 7 of 544
Pin Name
Pin No. Single-Chip Modes Flash Memory
TFP-144 Mode 2, Mode 3 (EXPE = 0) Programmer Mode
91 PC3 NC
92 PC2 NC
93 PC1 NC
94 PC0 NC
95 VSS VSS
96 P27
CE
97 P26 FA14
98 P25 FA13
99 P24 FA12
100 P23 FA11
101 P22 FA10
102 P21
OE
103 P20 FA8
104 P17/PW7 FA7
105 P16/PW6 FA6
106 P15/PW5 FA5
107 P14/PW4 FA4
108 P13/PW3 FA3
109 P12/PW2 FA2
110 P11/PW1 FA1
111 VSS VSS
112 P10/PW0 FA0
113 PB7/
WUE7
NC
114 PB6/
WUE6
NC
115 PB5/
WUE5
NC
116 PB4/
WUE4
NC
117 PB3/
WUE3
NC
118 PB2/
WUE2
NC
119 PB1/
WUE1/LSCI
NC
120 PB0/
WUE0/LSMI
NC
