2.2.2 Advanced Mode
• Address space
Linear access to a maximum address space of 16 Mbytes is possible.
• Extended registers (En)
The extended registers (E0 to E7) can be used as 16-bit registers. They can also be used as the
upper 16-bit segments of 32-bit registers or address registers.
• Instruction set
All instructions and addressing modes can be used.
• Exception vector table and memory indirect branch addresses
In advanced mode, the top area starting at H'00000000 is allocated to the exception vector
table in 32-bit units. In each 32 bits, the upper 8 bits are ignored and a branch address is stored
in the lower 24 bits (see figure 2.3). For details on the exception vector table, see section 4,
Exception Handling.
H'00000000
H'00000003
H'00000004
H'0000000B
H'0000000C
H'00000010
H'00000008
H'00000007
Reserved
Reserved
Reserved
Reset exception vector
(Reserved for system use)
Exception vector table
Exception vector 1
(Reserved for system use)
Figure 2.3 Exception Vector Table (Advanced Mode)
