Rev. 1.00, 05/04, page 376 of 544
R/W
Bit Bit Name
Initial
Value Slave Host Description
3 SDWNB 0 R/W — LPC Software Shutdown Bit
Controls host interface shutdown. For details of the LPC
shutdown function, and the scope of initialization by an
LPC reset and an LPC shutdown, see section 15.4.4,
Host Interface Shutdown Function (LPCPD).
0: Normal state
[Clearing conditions]
• Writing 0
• LPC hardware reset or LPC software reset
• LPC hardware shutdown
• LPC hardware shutdown release
(rising edge of
LPCPD signal when SDWNE = 0)
1: LPC software shutdown state
[Setting condition]
• Writing 1 after reading SDWNB = 0
2 PMEB 0 R/W — PME Output Bit
Controls PME output in combination with the PMEE bit.
For details, refer to description on the PMEE bit in
HICR0.
1 LSMIB 0 R/W — LSMI Output Bit
Controls LSMI output in combination with the LSMIE bit.
For details, refer to description on the LSMIE bit in
HICR0.
0 LSCIB 0 R/W — LSCI output Bit
Controls LSCI output in combination with the LSCIE bit.
For details, refer to description on the LSCIE bit in
HICR0.
