Renesas H8S/2111B User Manual
Page 517
Rev. 1.00, 05/04, page 483 of 544
Register Name
Abbreviation
Number
of Bits
Address Module
Data
Bus
Width
Number
of
Access
States
Keyboard control register H_1
KBCRH_1
8
H'FEDC
Keyboard
buffer
controller_1
8 2
Keyboard control register L_1
KBCRL_1
8
H'FEDD
Keyboard
buffer
controller_1
8 2
Keyboard data buffer register_1
KBBR_1
8
H'FEDE
Keyboard
buffer
controller_1
8 2
Keyboard control register H_2
KBCRH_2
8
H'FEE0
Keyboard
buffer
controller_2
8 2
Keyboard control register L_2
KBCRL_2
8
H'FEE1
Keyboard
buffer
controller_2
8 2
Keyboard data buffer register_2
KBBR_2
8
H'FEE2
Keyboard
buffer
controller_2
8 2
DDC switch register
DDCSWR
8
H'FEE6
IIC common 8
2
Interrupt control register A
ICRA
8
H'FEE8
INT
8
2
Interrupt control register B
ICRB
8
H'FEE9
INT
8
2
Interrupt control register C
ICRC
8
H'FEEA
INT
8
2
IRQ status register
ISR
8
H'FEEB
INT
8
2
IRQ sense control register H
ISCRH
8
H'FEEC
INT
8
2
IRQ sense control register L
ISCRL
8
H'FEED
INT
8
2
Address break control register
ABRKCR
8
H'FEF4
INT
8
2
Break address register A
BARA
8
H'FEF5
INT
8
2
Break address register B
BARB
8
H'FEF6
INT
8
2
Break address register C
BARC
8
H'FEF7
INT
8
2
Flash memory control register 1
FLMCR1
8
H'FF80
FLASH
8
2
Flash memory control register 2
FLMCR2
8
H'FF81
FLASH
8
2
Peripheral clock select register
PCSR
8
H'FF82
PWM
8
2
Erase block register 1
EBR1
8
H'FF82
FLASH
8
2
System control register 2
SYSCR2
8
H'FF83
SYSTEM
8
2
Erase block register 2
EBR2
8
H'FF83
FLASH
8
2
Standby control register
SBYCR
8
H'FF84
SYSTEM
8
2
