Rev. 1.00, 05/04, page 537 of 544

Appendix

A.

I/O Port States in Each Processing State

Table A.1

I/O Port States in Each Processing State

Port Name

Pin Name

Reset

Hardware

Standby

Mode

Software

Standby

Mode

Watch

Mode

Sleep

Mode

Sub-

sleep Mode

Subactive

Mode

Program

Execution

State

Port

1

T T

kept kept kept

kept

I/O port

I/O port

Port

2

T T

kept kept kept

kept

I/O port

I/O port

Port

3

T T

kept kept kept

kept

I/O port

I/O port

Port

4

T T

kept kept kept

kept

I/O port

I/O port

Port

5

T T

kept kept kept

kept

I/O port

I/O port

Port

6

T T

kept kept kept

kept

I/O port

I/O port

Port

7 T

T T T T T Input port

Input port

Port

8

T T

kept kept kept

kept

I/O port

I/O port

Port

97

T T

kept kept kept

kept

I/O port

I/O port

Port 96
φ
EXCL

T

T

[DDR = 1] H

[DDR = 0] T

EXCL input

[DDR = 1]

clock output

[DDR = 0] T

EXCL input

EXCL input

Clock output/

EXCL input/

input port

Ports 95 to 90

T T

kept kept kept kept

I/O port

I/O port

Port

A

T T

kept kept kept

kept

I/O port

I/O port

Port

B

T T

kept kept kept

kept

I/O port

I/O port

Ports C to G

T

T

kept

kept

kept

kept

I/O port

I/O port

[Legend]

H: High

L: Low

T: High-impedance

state

kept: Input ports are in the high-impedance state (when DDR = 0 and PCR = 1, input pull-up

MOSs remain on).

Output ports maintain their previous state.

Depending on the pins, the on-chip peripheral modules may be initialized and the I/O port
function determined by DDR and DR used.

DDR: Data direction register
