Rev. 1.00, 05/04, page 484 of 544
Register Name Abbreviation
Number
of Bits
Address Module
Data
Bus
Width
Number
of
Access
States
Low power control register LPWRCR 8 H'FF85 SYSTEM 8 2
Module stop control register H MSTPCRH 8 H'FF86 SYSTEM 8 2
Module stop control register L MSTPCRL 8 H'FF87 SYSTEM 8 2
Serial mode register_1 SMR_1 8 H'FF88 SCI_1 8 2
I 2 C bus control register_1 ICCR_1 8 H'FF88 IIC_1 8 2
Bit rate register_1 BRR_1 8 H'FF89 SCI_1 8 2
I 2 C bus status register_1 ICSR_1 8 H'FF89 IIC_1 8 2
Serial control register_1 SCR_1 8 H'FF8A SCI_1 8 2
Transmit data register_1 TDR_1 8 H'FF8B SCI_1 8 2
Serial status register_1 SSR_1 8 H'FF8C SCI_1 8 2
Receive data register_1 RDR_1 8 H'FF8D SCI_1 8 2
Smart card mode register_1 SCMR_1 8 H'FF8E SCI_1 8 2
I 2 C bus data register_1 ICDR_1 8 H'FF8E IIC_1 8 2
Second slave address register_1 SARX_1 8 H'FF8E IIC_1 8 2
I 2 C bus mode register_1 ICMR_1 8 H'FF8F IIC_1 8 2
Slave address register_1 SAR_1 8 H'FF8F IIC_1 8 2
Timer interrupt enable register TIER 8 H'FF90 FRT 8 2
Timer control/status register TCSR 8 H'FF91 FRT 8 2
Free running counter H FRCH 8 H'FF92 FRT 8 2
Free running counter L FRCL 8 H'FF93 FRT 8 2
Output control register AH OCRAH 8 H'FF94 FRT 8 2
Output control register BH OCRBH 8 H'FF94 FRT 8 2
Output control register AL OCRAL 8 H'FF95 FRT 8 2
Output control register BL OCRBL 8 H'FF95 FRT 8 2
Timer control register TCR 8 H'FF96 FRT 8 2
Timer output compare control register TOCR 8 H'FF97 FRT 8 2
Input capture register AH ICRAH 8 H'FF98 FRT 8 2
Output control register ARH OCRARH 8 H'FF98 FRT 8 2
Input capture register AL ICRAL 8 H'FF99 FRT 8 2
Output control register ARL OCRARL 8 H'FF99 FRT 8 2
Input capture register BH ICRBH 8 H'FF9A FRT 8 2
Output control register AFH OCRAFH 8 H'FF9A FRT 8 2
Input capture register BL ICRBL 8 H'FF9B FRT 8 2
