Rev. 1.00, 05/04, page 163 of 544
Bit Bit Name
Initial
Value R/W Description
2 OCIBE 0 R/W Output Compare Interrupt B Enable
Selects whether to enable output compare interrupt B
request (OCIB) when output compare flag B (OCFB) in
TCSR is set to 1.
0: OCIB requested by OCFB is disabled
1: OCIB requested by OCFB is enabled
1 OVIE 0 R/W Timer Overflow Interrupt Enable
Selects whether to enable a free-running timer overflow
request interrupt (FOVI) when the timer overflow flag
(OVF) in TCSR is set to 1.
0: FOVI requested by OVF is disabled
1: FOVI requested by OVF is enabled
0 — 0 R Reserved
This bit is always read as 1 and cannot be modified.
9.3.7 Timer Control/Status Register (TCSR)
TCSR is used for counter clear selection and control of interrupt request signals.
Bit Bit Name
Initial
Value R/W Description
7 ICFA 0 R/(W)* Input Capture Flag A
This status flag indicates that the FRC value has been
transferred to ICRA by means of an input capture
signal. When BUFEA = 1, ICFA indicates that the old
ICRA value has been moved into ICRC and the new
FRC value has been transferred to ICRA. Only 0 can be
written to this bit to clear the flag.
[Setting condition]
When an input capture signal causes the FRC value to
be transferred to ICRA
[Clearing condition]
Read ICFA when ICFA = 1, then write 0 to ICFA
