Rev. 1.00, 05/04, page 243 of 544

12.3.8 Serial

Interface Mode Register (SCMR)

SCMR selects SCI functions and its format.

Bit Bit

Name

Initial
Value R/W Description

7 to 4

All 1

R

Reserved

These bits are always read as 1 and cannot be
modified.

3 SDIR 0 R/W

Data

Transfer

Direction

Selects the serial/parallel conversion format.

0: TDR contents are transmitted with LSB-first.

Receive data is stored as LSB first in RDR.

1: TDR contents are transmitted with MSB-first.

Receive data is stored as MSB first in RDR.

The SDIR bit is valid only when the 8-bit data format is
used for transmission/reception; when the 7-bit data
format is used, data is always transmitted/received with
LSB-first.

2 SINV 0 R/W

Data

Invert

Specifies inversion of the data logic level. The SINV bit
does not affect the logic level of the parity bit. When
the parity bit is inverted, invert the O/

E bit in SMR.

0: TDR contents are transmitted as they are. Receive

data is stored as it is in RDR.

1: TDR contents are inverted before being transmitted.

Receive data is stored in inverted form in RDR.

1 —

1 R Reserved

This bit is always read as 1 and cannot be modified.

0

SMIF

0

R/W

Serial Communication Interface Mode Select:

0: Normal asynchronous or clocked synchronous mode

1: Reserved mode
