Rev. 1.00, 05/04, page vii of xxxiv
Rules:
Register name:
The following notation is used for cases when the same or a
similar function, e.g. serial communication interface, is
implemented on more than one channel:
XXX_N (XXX is the register name and N is the channel
number)
Bit order:
The MSB is on the left and the LSB is on the right.
Number notation:
Binary is B'xxxx, hexadecimal is H'xxxx, decimal is xxxx.
Signal notation:
An overbar is added to a low-active signal:
xxxx
Related Manuals:
The latest versions of all related manuals are available from our web site.
Please ensure you have the latest versions of all documents you require.
http://www.renesas.com/eng/
H8S/2111B manuals:
Document Title
Document No.
H8S/2111B Hardware Manual
This manual
H8S/2600 Series, H8S/2000 Series Programming Manual
REJ09B0139
User's manuals for development tools:
Document Title
Document No.
H8S, H8/300 Series C/C++ Compiler, Assembler, Optimizing Linkage Editor
User's Manual
REJ10B0058
Microcomputer Development Environment System H8S, H8/300 Series
Simulator/Debugger User's Manual
ADE-702-282
H8S, H8/300 Series High-performance Embedded Workshop 3 Tutorial
REJ10B0024
H8S, H8/300 Series High-performance Embedded Workshop 3
User's Manual
REJ10B0026
