Renesas H8S/2111B - Manual (Page 407)

Rev. 1.00, 05/04, page 373 of 544
R/W
Bit Bit Name
Initial
Value Slave Host Description
2 PMEE 0 R/W — PME output Enable
Controls PME output in combination with the PMEB bit
in HICR1.
PME pin output is open-drain, and an external
pull-up resistor is needed to pull the output up to V
CC
When the PME output function is used, the DDR bit for
P80 must not be set to 1.
PMEE PMEB
0 x: PME output disabled, other function of
pin is enabled
1 0: PME output enabled,
PME pin output
goes to 0 level
1 1: PME output enabled,
PME pin output is
high-impedance
1 LSMIE 0 R/W — LSMI output Enable
Controls LSMI output in combination with the LSMIB bit
in HICR1.
LSMI pin output is open-drain, and an external
pull-up resistor is needed to pull the output up to V
CC
When the LSMI output function is used, the DDR bit for
PB0 must not be set to 1.
LSMIE LSMIB
0 x: LSMI output disabled, other function of
pin is enabled
1 0: LSMI output enabled,
LSMI pin output
goes to 0 level
1 1: LSMI output enabled,
LSMI pin output is
high-impedance
0 LSCIE 0 R/W — LSCI output Enable
Controls LSCI output in combination with the LSCIB bit
in HICR1. LSCI pin output is open-drain, and an external
pull-up resistor is needed to pull the output up to V
CC
When the LSCI output function is used, the DDR bit for
PB1 must not be set to 1.
LSCIE LSCIB
0 x: LSCI output disabled, other function of
pin is enabled
1 0: LSCI output enabled, LSCI pin output
goes to 0 level
1 1: LSCI output enabled, LSCI pin output is
high-impedance
[Legend]
X: Don't care
