Rev. 1.00, 05/04, page 502 of 544
Register
Abbrevia-
tion Reset
High-Speed/
Medium-
Speed Watch Sleep
Sub-
Active Sub-Sleep
Module
Stop
Software
Standby
Hardware
Standby Module
PAODR Initialized — — — — — — — Initialized
PAPIN — — — — — — — — —
PADDR Initialized — — — — — — — Initialized
P1PCR Initialized — — — — — — — Initialized
P2PCR Initialized — — — — — — — Initialized
PORT
P3PCR Initialized — — — — — — — Initialized
P1DDR Initialized — — — — — — — Initialized
P2DDR Initialized — — — — — — — Initialized
P1DR Initialized — — — — — — — Initialized
P2DR Initialized — — — — — — — Initialized
P3DDR Initialized — — — — — — — Initialized
P4DDR Initialized — — — — — — — Initialized
P3DR Initialized — — — — — — — Initialized
P4DR Initialized — — — — — — — Initialized
P5DDR Initialized — — — — — — — Initialized
P6DDR Initialized — — — — — — — Initialized
P5DR Initialized — — — — — — — Initialized
P6DR Initialized — — — — — — — Initialized
PBODR Initialized — — — — — — — Initialized
PBPIN — — — — — — — — —
P8DDR Initialized — — — — — — — Initialized
P7PIN — — — — — — — — —
PBDDR Initialized — — — — — — — Initialized
P8DR Initialized — — — — — — — Initialized
P9DDR Initialized — — — — — — — Initialized
P9DR Initialized — — — — — — — Initialized
IER Initialized — — — — — — — Initialized INT
STCR Initialized — — — — — — — Initialized
SYSCR Initialized — — — — — — — Initialized
MDCR Initialized — — — — — — — Initialized
SYSTEM
BCR Initialized — — — — — — — Initialized
WSCR Initialized — — — — — — — Initialized
BSC
