Rev. 1.00, 05/04, page 162 of 544
9.3.6 Timer Interrupt Enable Register (TIER)
TIER enables and disables interrupt requests.
Bit Bit Name
Initial
Value R/W Description
7 ICIAE 0 R/W Input Capture Interrupt A Enable
Selects whether to enable input capture interrupt A
request (ICIA) when input capture flag A (ICFA) in
TCSR is set to 1.
0: ICIA requested by ICFA is disabled
1: ICIA requested by ICFA is enabled
6 ICIBE 0 R/W Input Capture Interrupt B Enable
Selects whether to enable input capture interrupt B
request (ICIB) when input capture flag B (ICFB) in
TCSR is set to 1.
0: ICIB requested by ICFB is disabled
1: ICIB requested by ICFB is enabled
5 ICICE 0 R/W Input Capture Interrupt C Enable
Selects whether to enable input capture interrupt C
request (ICIC) when input capture flag C (ICFC) in
TCSR is set to 1.
0: ICIC requested by ICFC is disabled
1: ICIC requested by ICFC is enabled
4 ICIDE 0 R/W Input Capture Interrupt D Enable
Selects whether to enable input capture interrupt D
request (ICID) when input capture flag D (ICFD) in
TCSR is set to 1.
0: ICID requested by ICFD is disabled
1: ICID requested by ICFD is enabled
3 OCIAE 0 R/W Output Compare Interrupt A Enable
Selects whether to enable output compare interrupt A
request (OCIA) when output compare flag A (OCFA) in
TCSR is set to 1.
0: OCIA requested by OCFA is disabled
1: OCIA requested by OCFA is enabled
