Rev. 1.00, 05/04, page 387 of 544

15.3.8

SERIRQ Control Registers 0 and 1 (SIRQCR0, SIRQCR1)

The SIRQCR registers contain status bits that indicate the SERIRQ operating mode and bits that
specify SERIRQ interrupt sources.

• SIRQCR0

R/W

Bit Bit

Name

Initial
Value Slave Host Description

7 Q/

C

0

R

Quiet/Continuous Mode Flag

Indicates the mode specified by the host at the end of
an SERIRQ transfer cycle (stop frame).

0: Continuous mode

[Clearing conditions]

• LPC hardware reset, LPC software reset
• Specification by SERIRQ transfer cycle stop frame

1: Quiet mode

[Setting condition]

• Specification by SERIRQ transfer cycle stop frame.

6

SELREQ 0

R/W

Start Frame Initiation Request Select

Selects whether start frame initiation is requested when
one or more interrupt requests are cleared, or when all
interrupt requests are cleared, in quiet mode.

0: Start frame initiation is requested when all interrupt

requests are cleared in quiet mode.

1: Start frame initiation is requested when one or more

interrupt requests are cleared in quiet mode.

5

IEDIR

0

R/W

Interrupt Enable Direct Mode

Specifies whether LPC channel 2 and channel 3
SERIRQ interrupt source (SMI, IRQ6, IRQ9 to IRQ11)
generation is conditional upon OBF, or is controlled only
by the host interrupt enable bit.

0: Host interrupt is requested when host interrupt enable

bit and corresponding OBF are both set to 1

1: Host interrupt is requested when host interrupt enable

bit is set to 1
