Register Name
Abbreviation
Number
of Bits
Address Module
Data
Bus
Width
Number
of
Access
States
Port 8 data direction register
P8DDR
8
H'FFBD
(write)
PORT 8 2
Port 7 input data register
P7PIN
8
H'FFBE
(read)
PORT 8 2
Port B data direction register
PBDDR
8
H'FFBE
(write)
PORT 8 2
Port 8 data register
P8DR
8
H'FFBF
PORT
8
2
Port 9 data direction register
P9DDR
8
H'FFC0
PORT
8
2
Port 9 data register
P9DR
8
H'FFC1
PORT
8
2
Interrupt enable register
IER
8
H'FFC2
INT
8
2
Serial timer control register
STCR
8
H'FFC3
SYSTEM
8
2
System control register
SYSCR
8
H'FFC4
SYSTEM
8
2
Mode control register
MDCR
8
H'FFC5
SYSTEM
8
2
Bus control register
BCR
8
H'FFC6
BSC
8
2
Wait state control register
WSCR
8
H'FFC7
BSC
8
2
Timer control register_0
TCR_0
8
H'FFC8
TMR_0
8
2
Timer control register_1
TCR_1
8
H'FFC9
TMR_1
8
2
Timer control/status register_0
TCSR_0
8
H'FFCA
TMR_0
8
2
Timer control/status register_1
TCSR_1
8
H'FFCB
TMR_1
16
2
Time constant register A_0
TCORA_0
8
H'FFCC
TMR_0
16
2
Time constant register A_1
TCORA_1
8
H'FFCD
TMR_1
16
2
Time constant register B_0
TCORB_0
8
H'FFCE
TMR_0
16
2
Time constant register B_1
TCORB_1
8
H'FFCF
TMR_1
16
2
Timer counter_0
TCNT_0
8
H'FFD0
TMR_0
16
2
Timer counter_1
TCNT_1
8
H'FFD1
TMR_1
16
2
PWM output enable register A
PWOERA
8
H'FFD3
PWM
8
2
PWM data polarity register A
PWDPRA
8
H'FFD5
PWM
8
2
PWM register select
PWSL
8
H'FFD6
PWM
8
2
PWM data registers 0 to 7
PWDR0 to
PWDR7
8 H'FFD7
PWM
8
2
I
2
C bus control register_0
ICCR_0
8
H'FFD8
IIC_0
8
2
I
2
C bus status register_0
ICSR_0
8
H'FFD9
IIC_0
8
2
I
2
C bus data register_0
ICDR_0
8
H'FFDE
IIC_0
8
2
Second slave address register_0
SARX_0
8
H'FFDE
IIC_0
8
2
