Rev. 1.00, 05/04, page 404 of 544

Figure 15.5 shows the timing of the

LPCPD and LRESET signals.

LPCPD

LRESET

LAD3–LAD0
LFRAME

LCLK

At least 30

µs

At least 100

µs

At least 60

µs

Figure 15.5 Power-Down State Termination Timing
