276 Database
Smoothing
on, [ off ]
Switches curve smoothing on/off. The smoothed curve will be shown as
dotted line.
Smoothing factor x axis
[ 0.01] ... 1000
Factor for smoothing on the x axis.
Smoothing factor y-axis
[ 0.01] ... 1000
Factor for smoothing on the y axis.
Also show original curve
on, [ off ]
If this option is switched on then the original curve (solid line) will be shown
in addition to the smoothed curve (dotted line, same color).
Options
Options for graphical presentation of curves.
Command type
[ DET ], MET, SET, KFT, KFC, STAT, MEAS, MEAS T/Flow, DOS
Selection of the command type for which the curve properties are to be de-
fined. The curve properties defined per command type are saved per curve
window and per client.
Note
When the dialog window is opened the particular
Command type that will be se-
lected as standard is that which applies for the curve shown in the curve win-
dow.
Autoscaling
[ on ], off
If this option is switched on then all axes in the curve window will be scaled
automatically.
Show grid
on, [ off ]
If this option is enabled then a grid will be shown against the background.
