Brocade 6910 Ethernet Access Switch Configuration Guide
769
53-1002581-01
Configuring Interface Settings for STA
36
•
BPDU Flooding - Enables/disables the flooding of BPDUs to other ports when global spanning
tree is disabled (
) or when spanning tree is disabled on specific port. When flooding
is enabled, BPDUs are flooded to all other ports on the switch or to all other ports within the
receiving port’s native VLAN as specified by the Spanning Tree BPDU Flooding attribute
(
•
Priority – Defines the priority used for this port in the Spanning Tree Protocol. If the path cost
for all ports on a switch are the same, the port with the highest priority (i.e., lowest value) will
be configured as an active link in the Spanning Tree. This makes a port with higher priority less
likely to be blocked if the Spanning Tree Protocol is detecting network loops. Where more than
one port is assigned the highest priority, the port with lowest numeric identifier will be enabled.
•
Default: 128
•
Range: 0-240, in steps of 16
•
Admin Path Cost – This parameter is used by the STA to determine the best path between
devices. Therefore, lower values should be assigned to ports attached to faster media, and
higher values assigned to ports with slower media. Note that path cost takes precedence over
port priority. (Range: 0 for auto-configuration, 1-65535 for the short path cost method
16
,
1-200,000,000 for the long path cost method)
By default, the system automatically detects the speed and duplex mode used on each port,
and configures the path cost according to the values shown below. Path cost “0” is used to
indicate auto-configuration mode. When the short path cost method is selected and the
default path cost recommended by the IEEE 8021w standard exceeds 65,535, the default is
set to 65,535.
•
Admin Link Type – The link type attached to this interface.
•
Point-to-Point – A connection to exactly one other bridge.
•
Shared – A connection to two or more bridges.
•
Auto – The switch automatically determines if the interface is attached to a point-to-point
link or to shared media. (This is the default setting.)
16. Refer to
“Configuring Global Settings for STA”
on page 763 for information on setting the path cost
method.
TABLE 158
Recommended STA Path Cost Range
Port Type
IEEE 802.1D-1998
IEEE 802.1w-2001
Ethernet
50-600
200,000-20,000,000
Fast Ethernet
10-60
20,000-2,000,000
Gigabit Ethernet
3-10
2,000-200,000
TABLE 159
Default STA Path Costs
Port Type
Short Path Cost
(IEEE 802.1D-1998)
Long Path Cost
(802.1D-2004)
Ethernet 65,535
1,000,000
Fast Ethernet
65,535
100,000
Gigabit Ethernet
10,000
10,000
