Brocade Communications Systems Brocate Ethernet Access Switch 6910 - Manual (Page 751)

Brocade 6910 Ethernet Access Switch Configuration Guide 701
53-1002581-01
Trunk Configuration
33
FIGURE 55 Configuring the LACP Aggregator Admin Key
To enable LACP for a port:
1. Click Interface, Trunk, Dynamic.
2. Select Configure Aggregation Port from the Step list.
3. Select Configure from the Action list.
4. Click General.
5. Enable LACP on the required ports.
6. Click Apply.
FIGURE 56 Enabling LACP on a Port
To configure LACP parameters for group members:
1. Click Interface, Trunk, Dynamic.
2. Select Configure Aggregation Port from the Step list.
3. Select Configure from the Action list.
4. Click Actor or Partner.
5. Configure the required settings.
6. Click Apply.
