52

Unified IP MIB Reference

53-1002549-02

draft-ietf-idr-bgp4-mibv2-12 MIB

BGP4v2 per-peer error management information

The following table contains the BGP4v2 per-peer error management information objects.

NOTE

The following table is supported only on the Brocade NetIron MLX, Brocade MLXe, Brocade NetIron
XMR, and Brocade NetIron CER series devices and it is not supported on the Brocade NetIron CES
2000 series BASE Packages device.

bgp4V2PeerState
brcdIp.3.5.1.1.2.1.13
Syntax: Integer

Read-only

Indicates the BGP peer connection states:

idle(1)

connect(2)

active(3)

opensent(4)

openconfirm(5)

established(6)

bgp4V2PeerDescription
brcdIp.3.5.1.1.2.1.14
Syntax: SnmpAdminString

Read-only

Specifies a user-configured description identifying the peer.
The object must contain a description that is unique within
the existing BGP instance for the peer.

Name, OID, and syntax

Access

Description

bgp4V2PeerErrorsTable
brcdIp.3.5.1.1.3

None

On a per-peer basis, the table reflects the last
protocol-defined error encountered and reported on the peer
session.

bgp4V2PeerLastErrorCodeReceived
brcdIp.3.5.1.1.3.1.1
Syntax: Unsigned32

Read-only

Specifies the last error code received from the peer through a
notification message on the connection. The field is zero(0), if
no error occurs.

bgp4V2PeerLastErrorSubCodeRece
ived
brcdIp.3.5.1.1.3.1.2
Syntax: Unsigned32

Read-only

Specifies the last error subcode received from the peer
through a notification message on the connection. The field is
zero(0), if no error occurs.

bgp4V2PeerLastErrorReceivedTime
brcdIp.3.5.1.1.3.1.3
Syntax: TimeStamp

Read-only

Indicates the time stamp when the last notification is
received from the peer.

bgp4V2PeerLastErrorReceivedText
brcdIp.3.5.1.1.3.1.4
Syntax: SnmpAdminString

Read-only

Specifies the implementation-specific explanation of the error
reported.

bgp4V2PeerLastErrorReceivedData
brcdIp.3.5.1.1.3.1.5
Syntax: Octet String
NOTE: This object is not supported

on Brocade NetIron MLX,
Brocade MLXe, Brocade
NetIron XMR, Brocade
NetIron CES, and Brocade
NetIron CER series devices

Read-only

Specifies the data of the last error code received by the peer.
As per RFC 2578, some implementations have limitations
dealing with Octet Strings that are larger than 255. So, the
data is truncated.

Name, OID, and syntax

Access

Description
