ifIndex to interface ID2 lookup table
ifIndex to interface ID2 lookup table
The ifIndex to interface ID2 lookup table maps ifindex values to the Interface ID lookup table. If the
provides an ifIndex, this table returns the interface ID value.
Name, OID, and syntax Access Description
snInterfaceLookup2Table
brcdIp.1.1.3.3.7 None The Interface ID2 to ifIndex lookup table.
snInterfaceLookup2InterfaceId
brcdIp.1.1.3.3.7.1.1
Syntax: InterfaceId Read-only Shows the interface ID, which consists of the following:
Octet 0 – Port type, which can be one of the following:
•
1 – Ethernet
•
2 – POS
•
3 – ATM
•
4 – Virtual
•
5 – Loopback
•
6 – GRE Tunnel
The values 1 - 6 applies to Brocade NetIron XMR, Brocade
NetIron MLX, and to Brocade MLXe router devices.
•
7 – ATM Subif
•
8 – MPLS Tunnel
•
9 – ATM PVC
•
10 – Management
•
11 – Trunk
•
12 – IP Tunnel (for IP tunnels, except MPLS)
The value also applies to 6 - 4 tunnels in Brocade NetIron
XMR, Brocade NetIron MLX, and Brocade MLXe router
devices.
Octet 1
•
If the value of Octet 0 is 1, 2, 3, 7, or 9, then this octet shows
the slot number of the device.
•
If the value of Octet 0 is 6 or 8, then this octet shows the
tunnel ID.
•
If the value of Octet 0 is 5, then this octet shows the loopback
ID.
•
If the value of Octet 0 is 4, then this octet shows a virtual ID.
Octet 2 – If the value of Octet 0 is 1, 2, 3, 7, or 9, then this octet
shows the port number.
Octet 3 – If the value of Octet 0 is 7 or 9, then this octet shows the
ATM Subif number.
Octet 4 – If the value of Octet 0 is 9, then this octet shows the ATM
VPI number.
Octet 5 – If the value of Octet 0 is 9, then this octet shows the ATM
VCI number.
snInterfaceLookup2IfIndex
brcdIp.1.1.3.3.7.1.2
Syntax: Integer32 Read-only Shows the interface in the ifIndex format.
