376
Unified IP MIB Reference
53-1002549-02
TM VOQ statistics table
NOTE
Expect a delay or latency of 25 seconds in the reported statistics values because of internal
cacheing of the statistics.
The Brocade NetIron devices can support the TM statistics aggregation only for traffic coming from
the following card types:
•
BR-MLX-10Gx8-X 8-port 10GbE Module
•
NI-MLX-10Gx8-D 8-port 10GbE Module
•
NI-MLX-10Gx8-M 8-port 10GbE (M) Module
•
BR-MLX-100Gx2-X 2-port 100GbE Module
•
NI-X-OC192x1 1-port OC192 STM64 Module
•
NI-X-OC192x2 2-port OC192 STM64 Module
•
NI-X-OC48x2 2-port OC48/12 STM16/STM4 Module
•
NI-X-OC48x4 4-port OC48/12 STM16/STM4 Module
•
NI-X-OC48x8 8-port OC48/12 STM16/STM4 Module
•
NI-MLX-1Gx48-T 48-port 10/100/1000Base-T MRJ21 Module
•
BR-MLX-1GCx24-X 24-port 10/100/1000Base-T Copper Module
•
BR-MLX-1GFx24-X 24-port 1GbE SFP Module
NOTE
The MIB objects in the following table are read-only and support only SNMP GET, GET-NEXT, WALK,
and GET-BULK requests.
Name, OID, and syntax
Access
Description
brcdTMDestUcastQStatTable
brcdIp.1.14.2.1.2.8
NA
The TM unicast queue counters aggregated across all the TMs
per destination interface per priority table.
brcdTMDestUcastQStatDestIfIn
dex
brcdIp.1.14.2.1.2.8.1.1
Syntax: InterfaceIndex
NA
The ifindex of the destination interface. The table includes all the
interfaces of the LP modules that are physically present and
operationally up and it also includes all the deployed LAG
interfaces.
brcdTMDestUcastQStatPriority
brcdIp.1.14.2.1.2.8.1.2
Syntax: PriorityTC
NA
The priority of the packets that are stored in the queue. This is a
1-based value. The priority0 maps to 1, priority1 maps to 2, and
so on.
The priority value equal to nonPriority(128) indicates the
aggregated counters for the given destination port. When
tm-max-queues is set to 4, the two consecutive priorities are
stored in one unicast queue.
Valid values: 1, 3, 5, 7, and 128
brcdTMDestUcastQStatEnqueP
kts
brcdIp.1.14.2.1.2.8.1.3
Syntax: Counter64
Read-only
The total aggregated count of the packets entering an ingress
queue across the TMs.
brcdTMDestUcastQStatEnqueBy
tes
brcdIp.1.14.2.1.2.8.1.4
Syntax: Counter64
Read-only
The total aggregated count of the bytes entering an ingress
queue across the TMs.
