Unified IP MIB Reference
381
53-1002549-02
TM multicast stream VOQ statistics table
TM multicast stream VOQ statistics table
The Traffic Manager multicast stream VOQ statistics table contains the multicast stream
queue-related statistics.
NOTE
The following table contains information of the TM multicast stream queue-related statistics on the
NI-MLX-1Gx48-T, NI-MLX-1Gx24, NI-MLX-10Gx8, BR-MLX-100Gx2, and all the POS modules.
brcdTMMcastQStatsQSize
brcdIp.1.14.2.2.4.1.16
Syntax: Unsigned32
Read-only
Shows the current size of the queue.
brcdTMMcastQStatsCreditCount
brcdIp.1.14.2.2.4.1.17
Syntax: Unsigned32
Read-only
Shows the current credit count of the queue.
Name, OID, and syntax
Access
Description
Name, OID, and syntax
Access
Description
brcdTMMcastStreamQStatsTable
brcdIp.1.14.2.2.5
None
The Traffic Manager multicast stream VOQ statistics
table.
brcdTMMcastStreamQStatsAddressType
brcdIp.1.14.2.2.5.1.1
Syntax: InetAddressType
None
Shows the value indicating the address family of the
address contained in
brcdTMMcastStreamQStatsSource and
brcdTMMcastStreamQStatsGroup.
brcdTMMcastStreamQStatsSource
brcdIp.1.14.2.2.5.1.2
Syntax: InetAddress
None
Shows the source IP address of the multicast
stream.
brcdTMMcastStreamQStatsGroup
brcdIp.1.14.2.2.5.1.3
Syntax: InetAddress
None
Shows the group IP address of the multicast stream.
brcdTMMcastStreamQStatsGroupPrefixLe
ngth
brcdIp.1.14.2.2.5.1.4
Syntax: InetAddressPrefixLength
None
Shows the length in bits of the mask which, when
combined with the corresponding value of
brcdTMMcastStreamQStatsGroup, identifies the
groups for which this entry contains queue
statistics.
brcdTMMcastStreamQStatsPriority
brcdIp.1.14.2.2.5.1.5
Syntax: Integer
Read-only
Shows the priority of the packets that will be stored
in the queue. Two consecutive priorities are stored
in one multicast stream queue:
•
Priority1And2 (1)
•
Priority3And4 (3)
•
Priority5And6 (5)
•
Priority7And8 (7)
brcdTMMcastStreamQStatsEnquePkts
brcdIp.1.14.2.2.5.1.6
Syntax: Counter64
Read-only
Shows the count of all packets entering ingress
queues on the TM.
