BGP4 attribute entries table
BGP4 attribute entries table
The BGP4 attribute entries table contains the sets of BGP4 attributes stored in the router’s
memory. Each set of attributes is unique and can be associated with one or more routes.
NOTE
The following table is not supported on the Brocade MLXe router, Brocade NetIron MLX, Brocade
NetIron XMR, Brocade NetIron CES, and Brocade NetIron CER series devices.
Name, OID, and syntax Access Description
snBgp4AttributeTable
brcdIp.1.2.11.18.1 None The BGP4 attribute entries table.
snBgp4AttributeIndex
brcdIp.1.2.11.18.1.1.1
Syntax: Integer32 Read-only Shows the index for a route entry.
snBgp4AttributeNextHop
brcdIp.1.2.11.18.1.1.2
Syntax: Integer Read-only Shows the IP address of the next-hop router for routes that have
this set of attributes.
snBgp4AttributeMetric
brcdIp.1.2.11.18.1.1.3
Syntax: Integer32 Read-only Shows the cost of the route entry.
snBgp4AttributeOrigin
brcdIp.1.2.11.18.1.1.4
Syntax: Integer Read-only Shows the origin of this route:
•
igp(0) – Routes with this set of attributes came to BGP
through IGP.
•
egp(1) – Routes with this set of attributes came to BGP
through EGP.
•
incomplete(2) – Routes came from an origin other than IGP
or EGP. For example, they may have been redistributed from
OSPF or RIP.
snBgp4AttributeAggregatorAs
brcdIp.1.2.11.18.1.1.5
Syntax: Integer32 Read-only Shows the aggregator AS number for an attribute entry. The AS in
which the network information in the attribute set was
aggregated. This value applies only to aggregated routes and is
otherwise 0.
snBgp4AttributeRouterId
brcdIp.1.2.11.18.1.1.6
Syntax: Integer Read-only Shows the ID of the device that originated this aggregator.
snBgp4AttributeAtomicAggrega
tePresent
brcdIp.1.2.11.18.1.1.7
Syntax: Integer Read-only Shows if this aggregation has resulted in information loss:
•
false(0) – No information loss.
•
true(1) – Information has been lost.
snBgp4AttributeLocalPreferenc
e
brcdIp.1.2.11.18.1.1.8
Syntax: Integer32 Read-only Shows the degree of preference for routes that use this set of
attributes, relative to other routes in the local AS.
