416
Unified IP MIB Reference
53-1002549-02
VRRP and VRRP-E virtual router configuration table
VRRP and VRRP-E virtual router configuration table
The following table replaces the
, which uses a slot or port number to index
entries. This new table uses the ifindex method to present the configuration and statistics for VRRP
and VRRP-E. Each entry in the table describes one VRRP or VRRP-E router.
NOTE
The following table is not supported on the Brocade MLXe router, Brocade NetIron MLX, Brocade
NetIron XMR, Brocade NetIron CES, and Brocade NetIron CER series devices.
snVrrpVirRtrTrackVifPortList
(Continued)
•
When the track port states first changes from up to down, the
interface’s preference level is reduced by the value of the
preference level parameter.
•
The next time the track port state changes from down to up, the
interface’s preference level is increased by the amount specified
by the preference level.
Name, OID, and syntax
Access
Description
Name, OID, and syntax
Access
Description
snVrrpVirRtr2Table
brcdIp.1.2.12.5.1
None
The VRRP virtual router 2 table.
snVrrpVirRtr2Id
brcdIp.1.2.12.5.1.1.1
Syntax: Integer
Read-only
Shows one of the VRIDs configured on this interface. If multiple VRIDs
are configured on the interface, there is an entry for each VRID.
snVrrpVirRtr2Ownership
brcdIp.1.2.12.5.1.1.2
Syntax: Integer
Read-write
Indicates the owner of the VRRP router interface. The owner or master
router owns the IP addresses associated with the VRID:
•
incomplete(0) – No IP address has been assigned to this VRRP or
VRRP-E interface.
•
owner(1) – The owner or the master router is the owner of the
VRRP router interface. This applies only to VRRP.
•
backup(2) – The backup router (VRRP or VRRP-E) is the owner of
the interface. This is the only value that can be assigned to a
VRRP-E router interface.
snVrrpVirRtr2CfgPriority
brcdIp.1.2.12.5.1.1.3
Syntax: Integer
Read-write
Indicates the preferability of a router for becoming the active router for
the interface. A higher number indicates a higher priority. If two or
more devices are tied with the highest priority, the backup interface
with the highest IP address becomes the active router for the VRID.
Valid values: 0 – 255, where:
•
0 – The master no longer participates in the VRRP and a backup
router should transition to be the new master.
•
255 – The router is the owner.
Default: 100.
snVrrpVirRtr2TrackPriori
ty
brcdIp.1.2.12.5.1.1.4
Syntax: Integer
Read-write
Applies to interfaces that are configured with track ports.
It indicates the priority of the track ports. The higher the number, the
higher the priority. Track port priority is always lower than the
“snVrrpVirRtrCfgPriority” priority.
This object dynamically adjusts the value of the
object when the track port state first
changes from up to down.
Valid values: 1 – 254
