78
Unified IP MIB Reference
53-1002549-02
LLDP-MIB
lldpStatsRxPortTable
The following table contains LLDP reception statistics for the individual ports.
lldpLocalSystemData
The following table lists the LLDP local system data objects.
lldpLocPortTable
The following table contains one or more rows per-port information associated with the local
system known to the agent.
Object
Object identifier
Supported?
lldpStatsTxPortNum
1.0.8802.1.1.2.1.2.6.1.1
Yes
lldpStatsTxPortFramesTotal
1.0.8802.1.1.2.1.2.6.1.2
Yes
Object
Object identifier
Supported?
lldpStatsRxPortNum 1.0.8802.1.1.2.1.2.7.1.1
Yes
lldpStatsRxPortFramesDiscardedTotal
1.0.8802.1.1.2.1.2.7.1.2
Yes
lldpStatsRxPortFramesErrors 1.0.8802.1.1.2.1.2.7.1.3
Yes
lldpStatsRxPortFramesTotal 1.0.8802.1.1.2.1.2.7.1.4
Yes
lldpStatsRxPortTLVsDiscardedTotal 1.0.8802.1.1.2.1.2.7.1.5
Yes
lldpStatsRxPortTLVsUnrecognizedTotal
1.0.8802.1.1.2.1.2.7.1.6
Yes
lldpStatsRxPortAgeoutsTotal 1.0.8802.1.1.2.1.2.7.1.7
Yes
Object
Object identifier
Supported?
lldpLocChassisIdSubtype
1.0.8802.1.1.2.1.3.1
Yes
lldpLocChassisId
1.0.8802.1.1.2.1.3.2
Yes
lldpLocSysName
1.0.8802.1.1.2.1.3.3
Yes
lldpLocSysDesc
1.0.8802.1.1.2.1.3.4
Yes
lldpLocSysCapSupported
1.0.8802.1.1.2.1.3.5
Yes
lldpLocSysCapEnabled 1.0.8802.1.1.2.1.3.6
Yes
Object
Object identifier
Supported?
lldpLocPortNum 1.0.8802.1.1.2.1.3.7.1.1
Yes
lldpLocPortIdSubtype 1.0.8802.1.1.2.1.3.7.1.2
Yes
lldpLocPortId 1.0.8802.1.1.2.1.3.7.1.3
Yes
lldpLocPortDesc 1.0.8802.1.1.2.1.3.7.1.4
Yes
