Unified IP MIB Reference 537
53-1002549-02
Chapter
52
Router IP RIP MIB
In this chapter
• IP RIP general group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 537
• IP RIP port configuration table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 539
• IP RIP redistribution table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 540
• IP RIP route filter table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 542
• IP RIP neighbor filter table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 543
• IP RIP port access table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 544
• Global RIP statistics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 544
IP RIP general group
The Routing Information Protocol (RIP) is an IP route exchange protocol that uses a distance vector
(a number representing distance) to measure the cost of a given route. The cost is a distance
vector because the cost often is equivalent to the number of hops between the Layer 3 Switch and
the destination network.
A Layer 3 Switch can receive multiple paths to a destination. A RIP route can have a maximum cost
of 15.
NOTE
The IP RIP MIBs are supported on the Brocade NetIron MLX, Brocade MLXe router, Brocade NetIron
XMR, Brocade NetIron CES, and Brocade NetIron CER series devices.
The following objects are general objects for RIP.
Name, OID, and syntax Access Description
snRtIpRipEnable
brcdIp.1.2.3.1.1
Syntax: Integer Read-write Indicates if IP RIP routing is enabled:
•
disabled(0)
•
enabled(1)
Default: disabled(0)
snRtIpRipUpdateTime
brcdIp.1.2.3.1.2
Syntax: Integer Read-write Specifies the RIP update interval in seconds.
Valid values: 1 – 21845 seconds
