BGP4 neighbor summary table
BGP4 neighbor summary table
The BGP4 neighbor summary table shows statistics for the router’s BGP4 neighbors.
Name, OID, and syntax Access Description
snBgp4NeighborSummaryTable
brcdIp.1.2.11.17.1 None The BGP4 neighbor summary table.
snBgp4NeighborSummaryIndex
brcdIp.1.2.11.17.1.1.1
Syntax: Integer32 Read-only The index for a route entry.
snBgp4NeighborSummaryIp
brcdIp.1.2.11.17.1.1.2
Syntax: IpAddress Read-only Shows the IP address of the neighbor.
snBgp4NeighborSummaryState
brcdIp.1.2.11.17.1.1.3
Syntax: Integer Read-only Shows the state of the BGP4 process during the current
session with the neighbor:
•
noState(0)
•
idle(1) – The BGP4 process is waiting to be started.
Usually, enabling BGP4 or establishing a neighbor
session starts the BGP4 process. A minus sign (-)
indicates that the session has gone down and the
software is clearing or removing routes.
•
connect(2) – Waiting for the connection process for the
TCP neighbor session to be completed.
•
active(3) – BGP4 is waiting for a TCP connection from
the neighbor.
•
openSent(4) – BGP4 is waiting for an OPEN message
from the neighbor.
•
openConfirm(5) – BGP4 has received an OPEN
message from the neighbor and is now waiting for
either a KEEPALIVE or NOTIFICATION message. If the
router receives a KEEPALIVE message from the
neighbor, the state changes to established(6). If the
message is a NOTIFICATION, the state changes to
idle(1).
•
established(6) – BGP4 is ready to exchange UPDATE
messages with the neighbor.
NOTE: If there is more BGP data in the TCP receiver queue,
a plus sign (+) is also displayed.
snBgp4NeighborSummaryStateCh
gTime
brcdIp.1.2.11.17.1.1.4
Syntax: Integer32 Read-only Shows the number of times the state of this neighbor has
changed. If the state frequently changes between CONNECT
and ACTIVE, there may be a problem with the TCP
connection.
snBgp4NeighborSummaryRouteRe
ceived
brcdIp.1.2.11.17.1.1.5
Syntax: Integer32 Read-only Shows the number of routes received from the neighbor
during the current BGP4 session.
snBgp4NeighborSummaryRouteIn
stalled
brcdIp.1.2.11.17.1.1.6
Syntax: Integer32 Read-only Indicates how many of the received routes were accepted
and installed in the BGP4 route table.
