Unified IP MIB Reference 401
53-1002549-02
Layer 2 ACL configuration table
fdryL2AclDestinationMac
brcdIp.1.2.2.15.7.1.6
Syntax: MAC address Read-write Optional destination MAC address. By default, it matches any
destination MAC address within a packet.
Default: '000000000000'H
fdryL2AclDestinationMacMask
brcdIp.1.2.2.15.7.1.7
Syntax: MAC address Read-write Optional destination MAC address mask. For a Set operation,
this object can only be used in conjunction with
fdryL2AclDestinationMac.
By default, it matches any destination MAC address within a
packet. If you want to match the first two bytes of the address
aabb.ccdd.eeff, use the mask ffff.0000.0000. In this case, the
clause matches all destination MAC addresses that contain
“aabb” as the first two bytes and any values in the remaining
bytes of the MAC address.
Default: '000000000000'H
fdryL2AclVlanId
brcdIp.1.2.2.15.7.1.8
Syntax:
“fdryVlanIdOrNoneTC”
Read-write The optional VLAN ID to match against the incoming packet. By
default, the VLAN ID field is ignored during the match and the
value 0 is returned.
Default: 0
fdryL2AclEthernetType
brcdIp.1.2.2.15.7.1.9
Syntax:
“fdryEnetTypeOrZeroTC”
Read-write The optional Ethernet type to match against the etype field of
the incoming packet. By default, the etype field is ignored during
the match.
Default: invalid
fdryL2AclDot1pPriority
brcdIp.1.2.2.15.7.1.10
Syntax:
“PortQosTC”
Read-write This object is optional. It assigns the traffic that matches the ACL
to a hardware-forwarding queue. In addition to changing the
internal forwarding priority, if the outgoing interface is an 802.1q
interface, this option maps the specified priority to its equivalent
802.1p (QoS) priority and marks the packet with the new 802.1p
priority. This option is applicable only for the inbound Layer 2
ACLs.
NOTE: The fdryL2AclDot1pPriority object following
fdryL2AclDot1pPriorityForce cannot be used together in
a Layer 2 ACL entry.
Default: level0(0)
fdryL2AclDot1pPriorityForce
brcdIp.1.2.2.15.7.1.11
Syntax:
“PortQosTC”
Read-write This object is optional. It assigns the packets of outgoing traffic
that match the Layer 2 ACL to a specific hardware-forwarding
queue, even though the incoming packet may be assigned to
another queue. This option is applicable only for the inbound
ACLs.
NOTE: The fdryL2AclDot1pPriority object following
fdryL2AclDot1pPriorityForce cannot be used together in
a Layer 2 ACL entry.
Default: level0(0)
fdryL2AclDot1pPriorityMapping
brcdIp.1.2.2.15.7.1.12
Syntax:
“PortQosTC”
Read-write This object is optional. It matches the packet's 802.1p value.
This option does not change the packet's forwarding priority
through the device or mark the packet. It is applicable for both
inbound and outbound Layer 2 ACLs.
Default: level0(0)
Name, OID, and syntax Access Description
