Unified IP MIB Reference 77
53-1002549-02
LLDP-MIB
• lldpStatsTxPortTable
• lldpStatsRxPortTable
• lldpLocalSystemData
• lldpLocPortTable
• lldpLocManAddrTable
• lldpRemTable
• lldpRemManAddrTable
• lldpRemUnknownTLVTable
• lldpRemOrgDefInfoTable
lldpPortConfigTable
The following table controls the LLDP frame transmission on the individual ports.
lldpConfigManAddrTable
The following table controls the selection of LLDP management address TLV instances to be
transmitted on the individual ports.
lldpstatistics
The following table lists the LLDP statistics group objects.
lldpStatsTxPortTable
The following table contains LLDP transmission statistics for the individual ports.
Object Object identifier Supported?
lldpPortConfigPortNum 1.0.8802.1.1.2.1.1.6.1.1 Yes
lldpPortConfigAdminStatus 1.0.8802.1.1.2.1.1.6.1.2 Yes
lldpPortConfigNotificationEnable 1.0.8802.1.1.2.1.1.6.1.3 Yes
lldpPortConfigTLVsTxEnable 1.0.8802.1.1.2.1.1.6.1.4 Yes
Object Object identifier Supported?
lldpConfigManAddrPortsTxEnable 1.0.8802.1.1.2.1.1.7.1.1 Yes
Object Object identifier Supported?
lldpStatsRemTablesLastChangeTime 1.0.8802.1.1.2.1.2.1 Yes
lldpStatsRemTablesInserts 1.0.8802.1.1.2.1.2.2 Yes
lldpStatsRemTablesDeletes 1.0.8802.1.1.2.1.2.3 Yes
lldpStatsRemTablesDrops 1.0.8802.1.1.2.1.2.4 Yes
lldpStatsRemTablesAgeouts 1.0.8802.1.1.2.1.2.5 Yes
