50
Unified IP MIB Reference
53-1002549-02
draft-ietf-idr-bgp4-mibv2-12 MIB
draft-ietf-idr-bgp4-mibv2-12 MIB
The following section of draft-ietf-idr-bgp4-mibv2-12 defines MIB objects for managing the Border
Gateway Protocol, version 4.
BGP4v2 per-peer session management information
The following table displays information about the BGP4v2 per-peer session management
information group. Use the show ip bgp neighbor
session management information.
NOTE
The following table is supported only on the Brocade NetIron MLX, Brocade MLXe, Brocade NetIron
XMR, and Brocade NetIron CER series devices and it is not supported on the Brocade NetIron CES
2000 series BASE Packages device.
bgp4PathAttrASPathSegment
1.3.6.1.2.1.15.6.1.5
This object is the sequence of AS path
segments. Each AS path segment is
represented by a triplet of
and
The Brocade NetIron XMR, Brocade NetIron
MLX, Brocade MLXe, Brocade NetIron CES, and
Brocade NetIron CER series devices return
“AS_TRANS” if the AS number is greater than 2
bytes.
bgp4PathAttrAggregatorAS
1.3.6.1.2.1.15.6.1.10
The AS number of the last BGP4 speaker that
performed route aggregation. A value of zero
(0) indicates the absence of this attribute.
The Brocade NetIron XMR, Brocade NetIron
MLX, Brocade MLXe, Brocade NetIron CES, and
Brocade NetIron CER series devices return
“AS_TRANS (23456)” for this object if remote
AS is greater than 16 bits.
Object group name
Object identifier
Notes
Name, OID, and syntax
Access
Description
bgp4V2PeerTable
brcdIp.3.5.1.1.2
None
The BGP4v2 per-peer table. The table contains one entry
per BGP peer and the information about the connections
with the BGP peers.
bgp4V2PeerInstance
brcdIp.3.5.1.1.2.1.1
Syntax: Unsigned32
None
Specifies the routing instance index. Some of the BGP
implementations permit the creation of multiple instances
of a BGP routing process. The implementations that do not
support multiple routing instances, return 1 for this object.
The VRF index is used to identify the peer instance. The VRF
index is a zero-based index.
bgp4V2PeerLocalAddrType
brcdIp.3.5.1.1.2.1.2
Syntax: InetAddressType
None
Specifies the address family of a local-end peering session.
The following address types are supported:
•
ipv4(1)
•
ipv6(2)
