Unified IP MIB Reference 627
53-1002549-02
AppleTalk zone table
AppleTalk zone table
The AppleTalk zone table shows the network numbers and zones learned on the network.
AppleTalk additional zone filter table
The AppleTalk additional zone filter table contains information about zones that do not match any
zones defined in the
“AppleTalk zone table” on page 627.
snRtATFwdCacheAction
brcdIp.1.2.10.5.1.7
Syntax: Integer Read-only Determines what the device will do if a match if found:
•
other(1)
•
forward(2)
•
forUs(3)
•
waitForArp(4)
•
dropPacket(5)
snRtATFwdCacheVLanId
brcdIp.1.2.10.5.1.8
Syntax: Integer Read-only Shows the ID of the VLAN associated with this entry. If set to zero,
then no VLAN is associated with this entry.
Name, OID, and syntax Access Description
Name, OID, and syntax Access Description
snRtATZoneTable
brcdIp.1.2.10.6 None AppleTalk zone table.
snRtATZoneIndex
brcdIp.1.2.10.6.1.1
Syntax: Integer Read-only Shows the table index for an AppleTalk zone table entry.
snRtATZoneNetStart
brcdIp.1.2.10.6.1.2
Syntax: ATNetworkNumber Read-only Shows the first AppleTalk network address in the range under this zone
name. (Refer to the
“snRtATZoneName” object.)
snRtATZoneNetEnd
brcdIp.1.2.10.6.1.3
Syntax: ATNetworkNumber Read-only Shows the last AppleTalk network addresses in the range under this
zone name.
snRtATZoneName
brcdIp.1.2.10.6.1.4
Syntax: DisplayString Read-only Shows the zone’s name. There can be up to 32 characters in this
object.
Name, OID, and syntax Access Description
snRtATAddZoneFilterTable
brcdIp.1.2.10.7 None The AppleTalk additional zone filter table.
snRtATAddZoneFilterPortIndex
brcdIp.1.2.10.7.1.1
Syntax: PortIndex Read-only Shows the port index for an additional zone filter table entry.
