Unified IP MIB Reference 577
53-1002549-02
VLAN CAR objects
VLAN CAR objects
The objects in the following table contain the rate limit configuration for VLANs. This table is
indexed by the
“snVLanCARVLanId” , “snVLanCARDirection” , and “snVLanCARRowIndex” objects.
Name, OID, and syntax Access Description
agRateLimitCounterTable
brcdIp.1.1.3.16.1.2 None The rate limit counter table.
agRateLimitCounterFwdedOctets
brcdIp.1.1.3.16.1.2.1.1
Syntax: Counter64 Read-only The forwarded octet count for this rate limit entry.
agRateLimitCounterDroppedOctets
brcdIp.1.1.3.16.1.2.1.2
Syntax: Counter64 Read-only The dropped octet count for this rate limit entry.
agRateLimitCounterReMarkedOctets
brcdIp.1.1.3.16.1.2.1.3
Syntax: Counter64 Read-only The remarked octet count for this rate limit entry.
agRateLimitCounterTotalOctets
brcdIp.1.1.3.16.1.2.1.4
Syntax: Counter64 Read-only The total octet count for this rate limit entry.
Name, OID, and syntax Access Description
snVLanCARTable
brcdIp.1.1.3.17.1.1 None The VLAN rate limit table.
snVLanCARVLanId
brcdIp.1.1.3.17.1.1.1.1
Syntax: Integer Read-only Shows the VLAN ID. VLAN ID is one of the indices of this table. Each
VLAN ID can have a membership of multiple ports.
Valid values: 1 – 4095
snVLanCARDirection
brcdIp.1.1.3.17.1.1.1.2
Syntax: Integer Read-only Specifies the transmission direction of the rate-limit object:
•
input(0) – For inbound traffic.
•
output(1) – For outbound traffic.
snVLanCARRowIndex
brcdIp.1.1.3.17.1.1.1.3
Syntax: Integer Read-only Shows the table index for rate limit objects for the VLAN. Rows are
numbered in sequential order. When a row is added, it is assigned the
next sequential number. When a row is deleted, the row is skipped.
snVLanCARType
brcdIp.1.1.3.17.1.1.1.4
Syntax: Integer Read-only Shows the type of traffic to which the rate limit is applied:
•
standardAcc(1) – Traffic matches standard access list.
•
quickAcc(2) – Traffic matches the rate limit access list.
•
all(3) – All traffic.
snVLanCARAccIdx
brcdIp.1.1.3.17.1.1.1.5
Syntax: Integer32 Read-only Indicates the index to the access list if the rate limit type is one of the
following:
•
standardAcc(1) – Traffic matches standard access list.
•
quickAcc(2) – Traffic matches the rate limit access list.
snVLanCARRate
brcdIp.1.1.3.17.1.1.1.6
Syntax: Integer32 Read-only Shows the committed access rate for long-term average transmission
for this VLAN in bits per second. Traffic that falls under this rate always
conforms to this rate.
