46

Unified IP MIB Reference

53-1002549-02

RFC 4087: IP Tunnel MIB

RFC 4087: IP Tunnel MIB

The following tables in RFC 4087 are supported on the Brocade NetIron XMR, Brocade NetIron
MLX, Brocade MLXe, Brocade NetIron CES, and Brocade NetIron CER series devices.

tunnelIfTable

The tunnelIfTable contains information on configured tunnels.

tunnelInetConfigTable

The tunnelInetConfigTable can be used to map a set of tunnel endpoints to the associated ifIndex
value. Every row in the tunnelIfTable with a fixed destination address should have a corresponding
row in the tunnelInetConfigTable.

Object names

Description

tunnelIfLocalAddress

Not supported as it is deprecated.

tunnelIfRemoteAddress

Not supported as it is deprecated.

tunnelIfEncapsMethod

Read-only. Only 6to4 and GRE tunnel types are supported. This is
the encapsulation method used by the tunnel.

tunnelIfHopLimit

Read-only. This is the IPv4 time-to-live (TTL) or IPv6 Hop Limit to
use in the outer IP header. A value of 0 indicates that the value is
copied from the payload's header.

tunnelIfSecurity

Read-only. Always returns none(1).

tunnelIfTOS

Read-only.

tunnelIfFlowLabel

Read-only. Always returns -1 which indicates a wildcard as
suggested by RFC 3595.

tunnelIfAddressType

Read-only.

tunnelIfLocalInetAddress

Read-only.

tunnelIfRemoteInetAddress

Read-only.

tunnelIfEncapsLimit

Read-only. This is the maximum number of additional
encapsulations permitted for packets undergoing encapsulation at
this node. A value of -1 indicates that no limit is present, except as
a result of the packet size.

Object names

Description

tunnelInetConfigAddressType

Read-only. Index value.

tunnelInetConfigLocalAddress

Read-only. Index value.

tunnelInetConfigRemoteAddress

Read-only. Index value.

tunnelInetConfigEncapsMethod

Read-only. Index value. This is the encapsulation method used by
the tunnel. Only 6to4 and GRE tunnel types are supported.

tunnelInetConfigID

Read-only. Index value. Always 1 in 6to4 tunnel type.

tunnelInetConfigIfIndex

Read-only.
