Unified IP MIB Reference 505
53-1002549-02
Chapter
50
OSPF MIB Definition
In this chapter
• OSPF general objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 505
• OSPF area table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 507
• Area range table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 508
• OSPF interface configuration tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 509
• OSPF interface 2 configuration table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 512
• OSPF virtual interface table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 515
• OSPF redistribution of routes table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 518
• OSPF neighbor table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 519
• OSPF virtual neighbor table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 521
• OSPF link-state database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 523
• OSPF link-state database (external). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 524
• OSPF area status table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 525
• OSPF interface status table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 526
• OSPF virtual interface status table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 529
• OSPF routing information table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 531
• Trap support objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 532
OSPF general objects
The objects in the following table are not supported on the Brocade NetIron MLX, Brocade MLXe
router, and Brocade NetIron XMR, Brocade NetIron CES, and Brocade NetIron CER series devices.
The Open Shortest Path First (OSPF) general objects provide information about the OSPF process.
and they apply globally to the routers.
Name, OID, and syntax Access Description
snOspfRouterId
brcdIp.1.2.4.1.1
Syntax: RouterID Read-write Shows the IP address of the Autonomous System Boundary Router
(ASBR). Conventionally, this ID defaults to the IP address of one of the
routers to ensure uniqueness in the network. This object contains a
32-bit integer.
snOspfAdminStat
brcdIp.1.2.4.1.2
Syntax: Integer Read-write Specifies the state of the OSPF in the router:
•
disabled(0) – OSPF is disabled on all interfaces.
•
enabled(1) – OSPF is active on at least one interface.
