588 Unified IP MIB Reference
53-1002549-02
MPLS or BGP Layer 3 VPN MIB
Proprietary extension
The following table lists the proprietary extension MIB objects.
MPLS or BGP Layer 3 VPN MIB
The MPLS or BGP Layer 3 VPN MIB (draft-ietf-lwvpn-mpls-vpn-mib-07.txt) is supported on the
Brocade NetIron XMR and the Brocade MLX series devices.
NOTE: The following objects are implemented as read-only:
• mplsL3VpnIfConfTable
• mplsL3VpnVrfTable
• mplsL3VpnVrfRTTable
• mplsL3VpnVrfRteTable
VPN interface configuration table
Name Access Supported?
fdryPwServiceType
brcdIp.3.1.2.1.20
Syntax: Integer None A L2VPN service type, used only for notification:
•
vll(1)
•
vlllocal(2)
•
vpls(3)
Object Object identifier Supported?
mplsL3VpnConfiguredVrfs brcdIp.3.2.1.1.1.1 Yes, but read-only.
mplsL3VpnActiveVrfs brcdIp.3.2.1.1.1.2 Yes, but read-only.
mplsL3VpnConnectedInterfaces brcdIp.3.2.1.1.1.3 Yes, but read-only.
mplsL3VpnNotificationEnable brcdIp.3.2.1.1.1.4 Yes, Read-write.
mplsL3VpnVrfConfMaxPossRts brcdIp.3.2.1.1.1.5 Yes, but read-only.
mplsL3VpnVrfConfRteMxThrshTime brcdIp.3.2.1.1.1.6 No
mplsL3VpnIllLblRcvThrsh brcdIp.3.2.1.1.1.7 No
Object Object Identifier Supported?
mplsL3VpnConf brcdIp.3.2.1.1.2 Yes
mplsL3VpnIfConfTable brcdIp.3.2.1.1.2.1 Yes, but read-only.
mplsL3VpnIfConfEntry brcdIp.3.2.1.1.2.1.1 Yes
mplsL3VpnIfConfIndex brcdIp.3.2.1.1.2.1.1.1 Yes
mplsL3VpnIfVpnClassification brcdIp.3.2.1.1.2.1.1.2 Yes
Only enterprise(2) is supported.
