Unified IP MIB Reference 565
53-1002549-02
PIM-SM
PIM RP candidate table
The PIM RP candidate table lists the IP multicast groups for which the local router is to advertise
itself as a candidate-RP. If this table is empty, the local router will advertise itself as a candidate-RP
for all groups. The snPimEnable object must be "enabled" before this table is read or written.
Name, OID, and syntax Access Description
snPimRPSetTable
brcdIp.1.2.9.2.3 None The PIM RP set table.
snPimRPSetGroupAddress
brcdIp.1.2.9.2.3.1.1
Syntax: IpAddress Read-only Shows the IP multicast group address. This object plus
snPimRPSetMask forms the group prefix for the
Ccandidate-RP.
snPimRPSetMask
brcdIp.1.2.9.2.3.1.2
Syntax: IpAddress Read-only Shows the IP multicast group address mask. This object
plus snPimRPSetGroupAddress forms the group prefix for
the candidate-RP.
snPimRPSetIPAddress
brcdIp.1.2.9.2.3.1.3
Syntax: IpAddress Read-only Shows the IP address of the candidate-RP.
snPimRPSetHoldTime
brcdIp.1.2.9.2.3.1.4
Syntax: Integer Read-only Shows the holdtime, in seconds, of a candidate-RP. If the
local router is not the BSR, this value is 0.
Valid values: 0 - 255
Name, OID, and syntax Access Description
snPimCandidateRPTable
brcdIp.1.2.9.2.4 None The PIM RP candidate table.
snPimCandidateRPGroupAddress
brcdIp.1.2.9.2.4.1.1
Syntax: IpAddress Read-only Shows the IP multicast group address mask. This object
combined with snPimCandidateRPMask forms the group
prefix for which the local router will advertise itself as a
candidate-RP.
snPimCandidateRPMask
brcdIp.1.2.9.2.4.1.2
Syntax: IpAddress Read-only Shows the multicast group address mask. This object
combined with snPimCandidateRPGroupAddress forms
the group prefix for which the local router will advertise
itself as a candidate-RP.
snPimCandidateRPIPAddress
brcdIp.1.2.9.2.4.1.3
Syntax: IpAddress Read-write Indicates the unicast IP address of the interface that will
be advertised as a candidate-RP.
snPimCandidateRPRowStatus
brcdIp.1.2.9.2.4.1.4
Syntax: Integer Read-write Controls the management of the table rows. The following
values can be written:
•
delete(3) – Deletes the row.
•
create(4) – Creates a new row.
•
modify(5) – Modifies an existing row.
If the row exists, then a SET with a value of create(4)
returns a "bad value" error. Deleted rows are removed
from the table immediately.
The following values can be returned on reads:
•
noSuch(0) – No such row.
•
invalid(1) – Row is inoperative.
•
valid(2) – Row exists and is valid.
