Unified IP MIB Reference 373
53-1002549-02
Chapter
39
Traffic Manager MIB Definition
In this chapter
• TM statistics information group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 373
• TM statistics table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 374
• TM VOQ statistics table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 375
• TM unicast VOQ statistics table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 377
• TM multicast VOQ statistics table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 379
• TM multicast stream VOQ statistics table . . . . . . . . . . . . . . . . . . . . . . . . . . 381
• TM CPU VOQ statistics table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 383
• TM CPU VOQ information table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 385
TM statistics information group
NOTE
This chapter describes the objects for the Traffic Manager (TM) statistics supported on the Brocade
NetIron MLX, Brocade MLXe, and Brocade NetIron XMR devices.
Use the clear tm statistics CLI command to clear both the CLI and SNMP statistics counters for the
Traffic Manager. Use the clear tm-voq-stats command to clear the VOQ statistics. The snmp-server
preserve-statistics CLI command does not preserve the TM statistics.
This table contains information about the TM statistics information group on the NI-MLX-1Gx48-T,
NI-MLX-1Gx24, NI-MLX-10Gx8, BR-MLX-100Gx2, and all the POS modules.
The show tm port-mapping CLI command displays information about the TM statistics information
group.
Name, OID, and syntax Access Description
brcdTMPortMappingMaxPorts
brcdIp.1.14.2.2.1.1
Syntax: Unsigned32 Read-only Shows the maximum number of ports that are
supported by the Traffic Manager on the system.
brcdTMPortMappingUsedPorts
brcdIp.1.14.2.2.1.2
Syntax: Unsigned32 Read-only Shows the currently used ports for this system
brcdTMPortMappingAvailablePorts
brcdIp.1.14.2.2.1.3
Syntax: Unsigned32 Read-only Shows the available ports on the system.
