Usage notes on CPU utilization and system CPU utility table
Group B consists of the following objects.
Group B was created to resolve the multi-management stations issue of snAgGblCpuUtilData.
These three objects are time-based. However, they only work for the management CPU utilization.
NOTE
The objects in Group B have been obsoleted on the Brocade NetIron XMR and Brocade NetIron MLX
devices.
Use snAgentCpuUtilTable on the Brocade NetIron XMR and Brocade NetIron MLX devices.
Use snAgentCpuUtilTable if supported on a device instead of snAgGblCpuUtil1SecAvg,
snAgGblCpuUtil5SecAvg, and snAgGblCpuUtil1MinAvg.
Group C consists of the snAgentCpu table.
MIB object OID
snAgGblCpuUtil1SecAvg brcdIp.1.1.2.1.50
snAgGblCpuUtil5SecAvg brcdIp.1.1.2.1.51
snAgGblCpuUtil1MinAvg brcdIp.1.1.2.1.52
MIB object OID
snAgentCpu brcdIp.1.1.2.11
snAgentCpuUtilTable brcdIp.1.1.2.11.1
snAgentCpuUtilEntry brcdIp.1.1.2.11.1.1
snAgentCpuUtilSlotNum brcdIp.1.1.2.11.1.1.1
snAgentCpuUtilCpuId brcdIp.1.1.2.11.1.1.2
snAgentCpuUtilInterval brcdIp.1.1.2.11.1.1.3
snAgentCpuUtilValue
NOTE: This object is deprecated for FastIron GS, and
FastIron SX devices and it is not supported on the
Brocade NetIron MLX, Brocade MLXe, Brocade
NetIron XMR, Brocade NetIron CES, and Brocade
NetIron CER series devices. Use the
snAgentCpuUtilPercent and
snAgentCpuUtil100thPercent objects for these
devices.
brcdIp.1.1.2.11.1.1.4
snAgentCpuUtilPercent
NOTE: Execute cpu-usage on command in the config
mode, if MP CPU utilization is needed on the
Brocade NetIron devices.
This object is supported on the Brocade NetIron
MLX, Brocade MLXe, Brocade NetIron XMR,
FastIron GS, and FastIron SX devices.
brcdIp.1.1.2.11.1.1.5
snAgentCpuUtil100thPercent
NOTE: This object is supported on Brocade NetIron MLX,
Brocade NetIron XMR, FastIron GS, FastIron SX,
as well as Brocade MLXe devices.
brcdIp.1.1.2.11.1.1.6
