Unified IP MIB Reference 225
53-1002549-02
System temperature table
System temperature table
This section displays the SNMP MIB objects for temperature readings on the Brocade NetIron MLX,
Brocade MLXe, Brocade NetIron XMR, Brocade NetIron CES, Brocade NetIron CER series, and on
the FastIron devices.
For stacking devices, refer to “System stacking temperature table” on page 226. The system
temperature table shows temperature reading information for each module’s temperature sensor.
System temperature threshold table
The following table lists the temperature levels of the fan settings.
NOTE
The new MP card MR2 supports all the objects in the System temperature threshold table. The
MP-MR2 is supported only on the Brocade NetIron XMR, Brocade NetIron MLX, and Brocade MLXe
devices.
Name, OID, and syntax Access Description
snAgentTempTable
brcdIp.1.1.2.13.1 None The table that displays the temperature reading for each module’s
temperature sensor. Note that temperature readings are displayed
only for those modules that have temperature sensors.
snAgentTempSlotNum
brcdIp.1.1.2.13.1.1.1
Syntax: Integer32 None The slot number of the module to which the temperature sensor is
attached.
snAgentTempSensorId
brcdIp.1.1.2.13.1.1.2
Syntax: Integer32 None The identification number of the module’s temperature sensor.
The following applies to the Management modules:
•
Sensor 1 – The intake temperature.
•
Sensor 2 – The exhaust-side temperature.
snAgentTempSensorDescr
brcdIp.1.1.2.13.1.1.3
Syntax: Display string Read-only The description of the temperature sensor.
snAgentTempValue
brcdIp.1.1.2.13.1.1.4
Syntax: Integer Read-only The temperature reading for the temperature sensor. This value is
displayed in units of 0.5º Celsius.
Valid values: 110 – 250
Name, OID, and syntax Access Description
snAgentTempThresholdTa
ble
brcdIp.1.1.2.13.2 None The table lists the temperature threshold levels for four speeds of fan
settings:
•
low
•
medium
•
medium-high
•
high
snAgentTempThresholdM
odule
brcdIp.1.1.2.13.2.1.1
Syntax: Integer None The module in the system for which threshold levels represented by
this row are applicable.
