Unified IP MIB Reference 83
53-1002549-02
LLDP-EXT-DOT3-MIB
lldpXdot1RemProtoVlanTable
The following table contains one or more rows per-port and per-protocol VLAN information about
the remote system received on the particular port.
lldpXdot1RemVlanNameTable
The following table contains one or more rows per IEEE 802.1Q VLAN name information about the
remote system received on the particular port.
lldpXdot1RemProtocolTable
The following table contains one or more rows per protocol information about the remote system
received on the particular port.
LLDP-EXT-DOT3-MIB
The following tables in the LLDP-EXT-DOT3-MIB are supported on the Brocade NetIron XMR,
Brocade NetIron MLX, Brocade MLXe, Brocade NetIron CES, and Brocade NetIron CER series
devices.
• lldpXdot3PortConfigTable
• lldpXdot3LocPortTable
• lldpXdot3LocPowerTable
• lldpXdot3LocLinkAggTable
• lldpXdot3LocMaxFrameSizeTable
Object Object identifier Supported?
lldpXdot1RemProtoVlanId 1.0.8802.1.1.2.1.5.32962.1.3.2.
1.1
Yes
lldpXdot1RemProtoVlanSupported 1.0.8802.1.1.2.1.5.32962.1.3.2.
1.2 Yes
lldpXdot1RemProtoVlanEnabled 1.0.8802.1.1.2.1.5.32962.1.3.2.
1.3 Yes
Object Object identifier Supported?
lldpXdot1RemVlanId 1.0.8802.1.1.2.1.5.32962.1.3.3.
1.1
Yes
lldpXdot1RemVlanName 1.0.8802.1.1.2.1.5.32962.1.3.3.
1.2 Yes
Object Object identifier Supported?
lldpXdot1RemProtocolIndex 1.0.8802.1.1.2.1.5.32962.1.3.4.
1.1
Yes
lldpXdot1RemProtocolId 1.0.8802.1.1.2.1.5.32962.1.3.4.
1.2
Yes
