584 Unified IP MIB Reference
53-1002549-02
Pseudo wire MIB
Draft-ietf-pwe3-pw-mib-11.txt
The following pseudo Wire (PW) MIB objects, as defined in draft-ietf-pwe3-pw-mib-11.txt, are
supported on the Brocade MLXe and Brocade NetIron series devices.
Draft-ietf-pwe3-pw-mib-11.txt obsoletes draft-ietf-pwe3-pw-mib-06.txt; however, some objects in
draft-ietf-pwe3-pw-mib-06.txt are still supported on the Brocade MLXe and Brocade NetIron series
devices. (Refer to
“Supported objects in draft-ietf-pwe3-pw-mib-06.txt” on page 586
Support for draft-ietf-pwe3-pw-mib-11.txt has been extended to VLL, VLL-local, and VPLS on the
Brocade MLXe and Brocade NetIron series devices. For additional objects, refer to
“VLL endpoint
table” on page 601, and “VPLS instance table” on page 603.
NOTE
Support for the following objects in draft-ietf-pwe3-pw-mib-11.txt provides read-only access.
pwLocalStatus brcdIp.3.1.2.1.2.1.39 If tunnel is down,
returns 0x80,
otherwise returns
0x00 Supported If tunnel is down, returns
0x80, otherwise returns
0x00
pwRemoteStatusC
apable brcdIp.3.1.2.1.2.1.40 notApplicable(1) notApplicable(
1) notApplicable(1)
pwRemoteStatus brcdIp.3.1.2.1.2.1.41 Always null Always null Always null
pwTimeElapsed brcdIp.3.1.2.1.2.1.42 Always 0 Always 0 Always 0
pwValidIntervals brcdIp.3.1.2.1.2.1.43 Always 0 Always 0 Always 0
pwRowStatus brcdIp.3.1.2.1.2.1.44 active(1) active(1) active(1)
pwStorageType brcdIp.3.1.2.1.2.1.45 permanent(4) permanent(4) permanent(4)
pwOamEnable brcdIp.3.1.2.1.2.1.46 false(2) false(2) false(2)
Object Object identifier Support for VLL Support for VLL-local Support for VPLS
pwindex brcdIp.3.1.2.1.2.1.
1 VLL-specific
encoding. One row
per VLL instance. VLL-local-specific
encoding. Two rows
per VLL-local instance,
one for each E.
Ethernet endpoint for
each instance. VPLS-specific
encoding. One row
per VPLS instance
and peer
combination.
pwEnetPwInstance brcdIp.3.1.4.1.1.1.
1 Always 1 1 for first endpoint, 2
for second Always 1
pwEnetPwVlan brcdIp.3.1.4.1.1.1.
2
•
VLAN ID
•
4097 for
pseudo wire in
raw mode
•
Default VLAN ID
for PW
untagged
frames
Always 4096 for raw
mode VPLS works in raw
mode.
Always 4096 in raw
mode. There is no
VLAN tagging in
outgoing packets.
TABLE 5 Support for the pwTable
Object Object identifier Support for VLL Support for
VLL-local Support for VPLS
