VLAN by IP subnet configuration table
NOTE
The following table is not supported on the Brocade MLXe router, Brocade NetIron MLX, Brocade
NetIron XMR, Brocade NetIron CES, and Brocade NetIron CER series devices.
Name, OID, and syntax Access Description
snVLanByIpSubnetTable
brcdIp.1.1.3.2.3 None The VLAN by IP subnet configuration table.
snVLanByIpSubnetEntry
brcdIp.1.1.3.2.3.1 None An entry in the VLAN by IP subnet configuration table.
snVLanByIpSubnetVLanId
brcdIp.1.1.3.2.3.1.1
Syntax: Integer Read-only Shows the VLAN ID index to both the VLAN by port information
table and this table.
Valid values: 1 - 4095
snVLanByIpSubnetIpAddress
brcdIp.1.1.3.2.3.1.2
Syntax: IpAddress Read-only Shows the IP address for the subnet of the protocol-based IP
VLAN.
snVLanByIpSubnetSubnetMask
brcdIp.1.1.3.2.3.1.3
Syntax: IpAddress Read-only Subnet mask associated with the subnet IP address.
snVLanByIpSubnetDynamic
brcdIp.1.1.3.2.3.1.4
Syntax: Integer Read-write Applies only to switches. Indicates whether or not dynamic port
inclusion is enabled:
•
disabled(0)
•
enabled(1)
snVLanByIpSubnetStaticMask
brcdIp.1.1.3.2.3.1.5
Syntax: PortMask Read-write Shows the port membership of the standalone switch VLAN by
Subnet in static mode.
This object was obsoleted.
snVLanByIpSubnetExcludeMask
brcdIp.1.1.3.2.3.1.6
Syntax: PortMask Read-write Shows the port membership of the standalone switch VLAN by
Subnet in exclusive mode.
This object was obsoleted.
snVLanByIpSubnetRouterIntf
brcdIp.1.1.3.2.3.1.7
Syntax: Integer Read-write Applies only to routers and is optional. It shows the virtual
interface of a router to the VLAN. Valid values: 0 - 60. It is not
configured if an SNMP-Get is equal to zero.
snVLanByIpSubnetRowStatus
brcdIp.1.1.3.2.3.1.8
Syntax: Integer Read-write Controls the management of the table rows. The following values
can be written:
•
delete(3) - Deletes the row.
•
create(4) - Creates a new row.
•
modify(5) - Modifies an existing row. If the row exists, then a
SET with a value of create(4) returns a "bad value" error.
Deleted rows are removed from the table immediately.
The following values can be returned on reads:
•
noSuch(0) - No such row.
•
invalid(1) - Row is inoperative.
•
valid(2) - Row exists and is valid.
snVLanByIpSubnetDynamicMask
brcdIp.1.1.3.2.3.1.9
Syntax: PortMask Read-only Shows the standalone switch VLAN by subnet active port
membership.
