14

Unified IP MIB Reference

53-1002549-02

RFC 2787: Definitions of Managed Objects for the Virtual Router Redundancy Protocol

RFC 2787: Definitions of Managed Objects for the Virtual Router
Redundancy Protocol

The Brocade NetIron XMR, Brocade NetIron MLX, Brocade MLXe, Brocade NetIron CES, and
Brocade NetIron CER series devices support RFC 2787, Definitions of Managed Objects for the
Virtual Router Redundancy Protocol.

NOTE

SNMP support for VRRP MIBs is limited only to IPv4.

The following are the VRRP MIB groups:

vrrpOperations (OID: 1.3.6.1.2.1.68.1)

vrrpStatistics (OID: 1.3.6.1.2.1.68.2)

vrrpConformance (OID: 1.3.6.1.2.1.68.3)

VRRP operations table (vrrpOperTable)

The operations table for a VRRP router that consists of a sequence (one or more conceptual rows)
of vrrpOperEntry objects.

VRRP associated IP address table (vrrpAssoIpAddrTable)

The table of addresses associated with the virtual router.

Object

Object identifier

Supported?

vrrpOperVrId

1.3.6.1.2.1.68.1.3.1.1

Yes

vrrpOperVirtualMacAddr

1.3.6.1.2.1.68.1.3.1.2

Yes

vrrpOperState

1.3.6.1.2.1.68.1.3.1.3

Yes

vrrpOperAdminState

1.3.6.1.2.1.68.1.3.1.4

Yes

vrrpOperPriority

1.3.6.1.2.1.68.1.3.1.5

Yes

vrrpOperIpAddrCount

1.3.6.1.2.1.68.1.3.1.6

Yes

vrrpOperMasterIpAddr

1.3.6.1.2.1.68.1.3.1.7

Yes

vrrpOperPrimaryIpAddr

1.3.6.1.2.1.68.1.3.1.8

Yes

vrrpOperAuthType

1.3.6.1.2.1.68.1.3.1.9

Yes

vrrpOperAuthKey

1.3.6.1.2.1.68.1.3.1.10

Yes

vrrpOperAdvertisementInterval

1.3.6.1.2.1.68.1.3.1.11

Yes

vrrpOperPreemptMode

1.3.6.1.2.1.68.1.3.1.12

Yes

vrrpOperVirtualRouterUpTime

1.3.6.1.2.1.68.1.3.1.13

Yes

vrrpOperProtocol

1.3.6.1.2.1.68.1.3.1.14

Yes

vrrpOperRowStatus

1.3.6.1.2.1.68.1.3.1.15

Yes
