526 Unified IP MIB Reference
53-1002549-02
OSPF interface status table
OSPF interface status table
The OSPF interface status table describes the interfaces from the viewpoint of OSPF. It augments
the ifStatusTable with OSPF-specific information.
NOTE
The following table is not supported on the Brocade MLXe router, Brocade NetIron XMR, Brocade
NetIron MLX, Brocade NetIron CES, and Brocade NetIron CER series devices.
snOspfAreaStatusASBdrRtrCount
brcdIp.1.2.4.11.1.1.7
Syntax: Gauge32 Read-only Shows the total number of Autonomous System border routers
that are reachable within this area. This is initially zero, the
default, and is calculated in each SPF pass.
snOspfAreaStatusLSACount
brcdIp.1.2.4.11.1.1.8
Syntax: Gauge32 Read-only Shows the total number of link-state advertisements in this
area’s link-state database, excluding AS external LSAs.
Default: 0
snOspfAreaStatusLSACksumSum
brcdIp.1.2.4.11.1.1.9
Syntax: Integer32 Read-only Shows the total link-state advertisements of area’s link-state
database. This number is a 32-bit unsigned sum of the LS
checksums, excluding external (LS type 5) link-state
advertisements. The value can be used to determine if there has
been a change in a router’s link-state database, and to compare
the link-state database of two routers.
Default: 0
snOspfAreaStatusAreaIdFormat
brcdIp.1.2.4.11.1.1.10
Syntax: Integer Read-only Specifies the format of how Area ID will be entered in the
“snOspfAreaStatusAreaId” object:
•
integer(0) – Integer.
•
ipAddress(1) – IP address.
Name, OID, and syntax Access Description
Name, OID, and syntax Access Description
snOspfIfStatusTable
brcdIp.1.2.4.12.1 None The OSPF interface status table.
snOspfIfStatusEntryIndex
brcdIp.1.2.4.12.1.1.1
Syntax: Integer32 Read-only The ID of an entry in the OSPF interface status table.
snOspfIfStatusPort
brcdIp.1.2.4.12.1.1.2
Syntax: Integer32 Read-only Shows the ID of the physical router port of this OSPF interface.
snOspfIfStatusIpAddress
brcdIp.1.2.4.12.1.1.3
Syntax: IpAddress Read-only Shows the IP address of this OSPF interface.
snOspfIfStatusAreaId
brcdIp.1.2.4.12.1.1.4
Syntax: AreaID Read-only Identifies the area to which the interface connects. This ID is a 32-bit
integer. Area ID 0.0.0.0 (in the ’00000000’h format) is used for the
OSPF backbone.
The format of this ID is determined by the value of the
“snOspfIfStatusAreaIdFormat” object.
