Configuring an HSG80 Array Controller 2–19
Use the following steps and Figure 2–7 to connect your dual-redundant
controllers to the host using two hubs with optical support:
Figure 2–7 Cabling for Dual-Redundant Configuration with Two Hubs using Fibre Channel
Optical Support
1 2 3 4 5 6
CXO6496A
2
3
1
1 2 3 4 5 6
2
To host
To host
