C–6 HSG80 User’s Guide
■● ❍ ●❍ ●❍ 2A All cabinet IO modules are not of
the same type
Cabinet I/O modules are a
combination of single-sided and
differential
Ensure that the I/O modules in an
extended subsystem are either all
single-ended or all differential, not
both.
■● ❍ ●❍ ❍ ● 29 EMU protocol version
incompatible
The microcode in the EMU and
the software in the controller are
not compatible
Upgrade either the EMU microcode or
the software (refer to the Release Notes
that accompanied the controller’s
software).
■● ❍ ●❍ ❍ ❍ 28 An unexpected Machine Fault/
NMI occurred during Last Failure
processing
A machine fault was detected
while a Non-Maskable Interrupt
was processing
Reset the controller
■● ❍ ❍ ● ●● 27 Memory module has insufficient
usable memory Replace indicated DIMM(s)
(this indication is only provided when
Fault LED logging is enabled).
■● ❍ ❍ ● ●❍ 26 Indicated memory module is
missing
Controller is unable to detect a
particular memory module
Insert memory module (cache board)
Table C–1 Solid OCP Patterns (Continued)
Pattern
OCP
Code
Error Repair Action
