Troubleshooting 4–25
Figure 4–3 Regions on the Device Display
VTDPY>DISPLAY DEVICE
S/N: ZG64100176 SW: v7.0 HW: CX-02
67% I/D 99.9% Idle 0 KB/S Up: 0 5:17.54
Checking Device Type and Location
The device map region of the device display (upper left) shows all of
the devices that the controller recognizes through its device ports. Table
4–5 lists the heading and contents for each column of the device map
region.
Target PTL ASWF Rq/S RdKB/S WrKB/S Que Tg CR BR TR
111111 P1120 A^ 0 0 0 0 0 0 0 0
0123456789012345 D1130 A^ 0 0 0 0 0 0 0 0
P1 hH PDD D1140 A^ 0 0 0 0 0 0 0 0
o2 hH DDD D2120 A^ 0 0 0 0 0 0 0 0
r3 ????hH D2130 A^ 0 0 0 0 0 0 0 0
t4 hH DDD D2150 a^ 0 0 0 0 0 0 0 0
5 P hH ?3020 ^F 0 0 0 0 0 0 0 0
6 DDD hH ?3030 ^F 0 0 0 0 0 0 0 0
?3040 ^F 0 0 0 0 0 0 0 0
?3050 ^F 0 0 0 0 0 0 0 0
D4090 A^ 0 0 0 0 0 0 0 0
D4100 A^ 0 0 0 0 0 0 0 0
D4110 A^ 0 0 0 0 0 0 0 0
P5030 A^ 0 0 0 0 0 0 0 0
D6010 A^ 0 0 0 0 0 0 0 0
D6020 A^ 0 0 0 0 0 0 0 0
D6030 A^ 0 0 0 0 0 0 0 0
Port Rq/S RdKB/S WrKB/S CR BR TR
1 0 0 0 0 0 0
2 0 0 0 0 0 0
3 0 0 0 0 0 0
4 0 0 0 0 0 0
5 0 0 0 0 0 0
6 0 0 0 0 0 0
Table 4–5 Device Map Columns
Column Contents
Port SCSI ports 1 through 6.
Target SCSI targets 0 through 15. Single controllers occupy 7;
dual-redundant controllers occupy 6 and 7.
D = disk drive or CD-ROM drive
F = foreign device
H = this controller
h = other controller in dual-redundant configurations
